24V 100W High-Temperature Resistant Micro Electric Diaphragm Pump (L0742YD-24-100F)
Power through demanding fluid-transfer tasks with this compact yet capable 24V 100W self-priming micro electric diaphragm pump. Engineered for high-temperature environments and built with a robust diaphragm sealing structure, this booster pump delivers reliable, consistent performance across commercial, industrial, and appliance applications — all in a lightweight 1,100 g form factor.
Key Features
- High-Temperature Resistant Construction — Designed to handle elevated operating temperatures, making it ideal for steam equipment, hot-water circulation, and similar demanding setups.
- Self-Priming Design — Starts pumping without manual priming, saving time and simplifying installation.
- Powerful 100W Electric Motor — Delivers a maximum flow rate of 7 L/min and maximum pressure of 1.0 MPa for strong, steady water movement.
- Diaphragm Sealing Structure — Provides excellent leak resistance and compatibility with clean water and alcohol-based liquids.
- Compact & Lightweight — Weighing only 1,100 g, this pump fits easily into tight spaces and portable equipment.
- 1/2" External Thread Outlet — Standard 4-minute external thread connection for straightforward plumbing integration.
- Quality-Tested Before Shipment — Every unit undergoes a water test prior to dispatch to ensure full operational integrity. Minor residual moisture is normal and the pump is brand new.
Product Specifications
| Specification | Value |
|---|---|
| Model Number | L0742YD-24-100F |
| Voltage | 24V DC |
| Power (Max) | 100W |
| Pressure (Max) | 1.0 MPa |
| Flow Rate (Max) | 7 L/min |
| Pump Structure | Diaphragm Pump |
| Sealing Material | Diaphragm |
| Chemical Compatibility | Clean Water, Alcohol |
| Outlet Size | 1/2" 4-Minute External Thread |
| Weight | 1,100 g |
| Motor Type | Electric |
| Pressure Range | Low Pressure |
| Country of Origin | Made in China (Zhejiang) |
Common Applications
- Steam ironing machines
- Tube and pipe cleaning systems
- Commercial building water boosting
- Industrial water recycling circuits
- Fluid transfer in appliances and equipment
Learn more: OSHA guidance on hand and power tools
Frequently Asked Questions
Q: What liquids is the L0742YD-24-100F diaphragm pump compatible with?
A: This micro electric diaphragm pump is compatible with clean water and alcohol-based liquids. It is not designed for abrasive, highly corrosive, or particulate-laden fluids. Always verify chemical compatibility with your specific application before use.
Q: Does this 24V diaphragm pump require manual priming before operation?
A: No — the L0742YD-24-100F features a self-priming design, meaning it can draw fluid automatically without manual priming, making installation and startup quick and straightforward.
Q: Why might there be water or moisture inside the pump packaging when it arrives?
A: Every unit is individually water-tested before shipment to verify normal operation. Any residual moisture or water stains you notice upon unboxing are a result of this quality-assurance process — the pump is brand new and has not been used.
Q: What is the maximum pressure and flow rate of this booster pump?
A: The pump delivers a maximum pressure of 1.0 MPa and a maximum flow rate of 7 L/min at 24V DC / 100W, making it well-suited for booster and fluid-transfer applications in commercial and industrial settings.
Production & Packaging Notice
To maintain high stock availability and fast shipping times, our items are sourced from multiple verified manufacturing facilities. While the core quality, materials, and product specifications remain identical, you may notice slight variations in the packaging design, manufacturing origin, or the wording of the printed instructions.
