433MHz Universal Garage Door Remote Control Duplicator Cloner

433MHz Universal Remote Control Duplicator – Clone Your Garage or Gate Remote Instantly

Upgrade or replace your existing garage door, gate, or access control remote with this 433MHz / 433.92MHz Universal Remote Control Duplicator. Compact, lightweight, and designed for fast cloning, this 4-channel wireless remote lets you copy fixed-code and learning-code remotes in seconds — no programming experience required.

Product Specifications

• Frequency: 433 MHz / 433.92 MHz
• Channels: 4
• Dimensions: 60 × 36 × 12 mm
• Material: Durable ABS Plastic
• Rated Voltage: 12V (battery included)
• Wireless Range: 50–150 m (open space)
• Compatible Uses: Electric telescopic doors, road gate barriers, garage doors, alarm systems, and more
• Country of Origin: Made in China

Compatible Chip Types

This duplicator works with a wide range of fixed-code and learning-code chips, including:

PT2260 / SC2260 / LX2260 / HX2260 · PT2262 / SC2262 / LX2262 / HS2262 / HX2262 · PT2264 · PT2240 / LX2240 · EV1527 / HS1527 / HX1527 · FP527 · CS5211 · SMC918 · SMC926 · AX5026 · AX5326-3 · AX5326-4 · HT600 · HT680 · HT6207 · HT6010 / HT6012 / HT6013 / HT6014 · HT12D · HT46F49E · PIC16F629 · PIC16F630, and more.

Note: Different manufacturers may use different prefix letters — compatibility is determined by the numeric portion of the chip model number.

Key Features

• ✅ Universal Compatibility – Works with most 433MHz fixed-code and learn-code garage doors and gate openers
• ✅ 4-Channel Design – Clone up to 4 separate buttons from your original remote
• ✅ Long Wireless Range – Up to 150 meters in open space
• ✅ Quick & Easy Cloning – Simple button-press pairing process, no tools needed
• ✅ Code Restore Function – Accidentally cleared a code? Restore it with ease
• ✅ Battery Included – Ready to use right out of the box
• ✅ Slim & Portable – Ultralight design fits easily on your keychain or in a pocket

How to Use

Step 1 – Clear Code

Hold the unlock and lock keys simultaneously. The LED will flash rapidly 3 times. Keep one finger held, then quickly click the released button 3 times until the LED flashes rapidly. Release both fingers, then press any key. When the LED turns off, the code has been cleared successfully.

Step 2 – Copy / Clone

Hold both the original remote and the new duplicator as close together as possible. Press the first button on both remotes simultaneously. The LED will flash twice in about 2 seconds, then continue flashing. Release both buttons. Press the copied key — if the light stays on, the code has been cloned successfully. Repeat for each additional button.

Step 3 – Restore

If a code is accidentally cleared, press the bottom two buttons on the duplicator simultaneously. The LED will flash — release, then press any key. A long light indicates the code has been restored.

For Rolling Code Remotes

1. Clear code: Press A and B together, then keep A held and press B three times — the light will flash.
2. Copy: Press the A button on both remotes simultaneously — the light will turn on to confirm copy.
3. Press the Learn button on the original remote's receiver and the A button on the new remote at the same time to finalize.

Important Notes

• Only compatible with fixed code, learn code, and select microcontroller-based remotes at 433MHz.
• Rolling code encryption chips (e.g. HCS200, HCS201, HCS300, HCS301) cannot be duplicated — this is a hardware limitation inherent to rolling code encryption technology.
• Ensure the original remote is functioning normally and has sufficient battery before cloning.
• Please allow ±1–3mm variance due to manual measurement.
• Actual color may vary slightly from photos due to monitor and lighting differences.

What's in the Box

• 1 × 433MHz Remote Control Duplicator (battery included)

Learn more: OSHA on personal protective equipment

Frequently Asked Questions

Q: What types of remotes can this 433MHz duplicator clone?

A: This universal remote control duplicator is compatible with most 433MHz fixed-code and learning-code remotes. Supported chip types include PT2262, EV1527, HT12D, PIC16F629, and many others. It works with garage door openers, gate barriers, alarm systems, and electric telescopic doors that operate on the 433MHz or 433.92MHz frequency.

Q: Can this duplicator copy rolling code remotes like HCS301?

A: Rolling code encryption chips such as HCS200, HCS201, HCS300, and HCS301 cannot be duplicated by this device. Rolling code technology generates a new code with every press for added security, which prevents standard cloning. This duplicator is designed for fixed and learning-code systems only.

Q: Does the battery come included, and what voltage does it use?

A: Yes, a 12V battery is included with the remote control duplicator, so it is ready to use immediately out of the box. No additional purchases are required to get started.

Q: How far can this remote control operate from the receiver?

A: In open space, this 433MHz duplicator has a wireless transmission range of approximately 50 to 150 meters, making it suitable for most residential driveways, parking facilities, and gate entrances.
