49E Linear Hall Sensor Module for STM32, Arduino & Raspberry Pi
Detect magnetic fields and measure rotating object positions with precision using this compact 49E Linear Hall Sensor Module. Whether you're building a brushless motor controller, an encoder replacement, or a proximity detection system, this digital magnetic sensor delivers reliable, real-time output. Compatible with STM32, Arduino, and Raspberry Pi platforms out of the box, complete with ready-to-use code routines so you can get started immediately.
Key Features
- Digital Output: Clean, noise-resistant digital signal ideal for microcontroller integration
- Magnetic Sensing Technology: Detects changes in magnetic flux for accurate rotational and positional measurement
- Multi-Platform Compatible: Includes routines for STM32, Arduino, and Raspberry Pi — no extra setup needed
- Low Power Operation: Runs at 3.3V with only 0.1A working current — efficient for battery-powered and embedded projects
- Compact & Lightweight: Measures just 27 × 15 × 5 mm and weighs only 8g — easy to integrate into tight spaces
- General Purpose: Suitable for a wide range of DIY electronics, robotics, automation, and educational projects
Technical Specifications
| Model | 49E Linear Hall Sensor |
| Sensor Category | Magnetic Sensor |
| Output Type | Digital Sensor |
| Working Voltage | 3.3V |
| Working Current | 0.1A |
| Dimensions | 27 × 15 × 5 mm |
| Weight | 8g |
| Material | Mixture (composite) |
| Country of Origin | Made in China |
What's Included
- 1 × 49E Linear Hall Sensor Module
- Code routines for STM32, Arduino, and Raspberry Pi
Ideal Applications
- Brushless DC (BLDC) motor position feedback
- Rotational speed and angle measurement
- Proximity and end-stop detection in robotics
- DIY encoders and automation projects
- STEM education and prototyping
