MAX31865 RTD Platinum Resistance Temperature Detector Module — PT100 to PT1000
The MAX31865 RTD Temperature Detector Module is a precision temperature sensing solution designed for engineers, makers, and electronics enthusiasts who demand accurate and reliable temperature readings. Compatible with a wide range of platinum resistance temperature detectors — from PT100 to PT1000 — this module makes it easy to integrate high-accuracy temperature sensing into your Arduino, Raspberry Pi, or any SPI-compatible microcontroller project.
Key Features
- Wide Compatibility: Supports PT100, PT500, and PT1000 platinum RTD sensors for flexible use across a broad range of applications.
- High Accuracy: The MAX31865 IC delivers precise resistance-to-digital conversion, providing reliable temperature data for demanding projects.
- SPI Interface: Standard 4-wire SPI communication makes integration with microcontrollers fast and straightforward.
- 2, 3, or 4-Wire RTD Support: Versatile wiring configuration options allow compatibility with most commercially available PT100/PT1000 probes.
- Fault Detection: Built-in fault detection circuitry alerts you to sensor faults including over/under range and short circuits.
- Compact Form Factor: Small PCB footprint is ideal for integration into enclosures, prototyping boards, or embedded systems.
- Condition: Brand new.
Technical Specifications
- IC: MAX31865
- Compatible Sensors: PT100 to PT1000 platinum RTD
- Interface: SPI (Serial Peripheral Interface)
- RTD Wiring: 2-wire, 3-wire, and 4-wire configurations supported
- Supply Voltage: 3.3V / 5V compatible
- Condition: New
- Made in Mainland China
What's in the Box
- 1 × MAX31865 RTD Platinum Resistance Temperature Detector Module
Ideal Applications
- Industrial temperature monitoring and data logging
- DIY electronics and maker projects
- Arduino and Raspberry Pi temperature sensing setups
- Laboratory and scientific instrumentation
- HVAC and environmental monitoring systems
- 3D printer heated bed or hotend temperature control
Learn more: OSHA guidance on hand and power tools
Frequently Asked Questions
Q: What microcontrollers are compatible with the MAX31865 RTD Temperature Detector Module?
A: The MAX31865 module uses a standard SPI interface, making it compatible with virtually any SPI-capable microcontroller, including Arduino (Uno, Mega, Nano), Raspberry Pi, ESP8266, ESP32, and more. Many open-source libraries are available to help you get started quickly.
Q: Can the MAX31865 module work with both PT100 and PT1000 sensors?
A: Yes! The MAX31865 RTD module supports platinum resistance sensors across the full PT100 to PT1000 range. You can configure the on-board reference resistor to suit your specific sensor type, giving you maximum flexibility for your project.
Q: Does this module support 2-wire, 3-wire, and 4-wire RTD connections?
A: Absolutely. The MAX31865 module supports 2-wire, 3-wire, and 4-wire RTD wiring configurations. The wiring mode can be selected via on-board solder jumpers or configuration registers, allowing you to minimize errors introduced by lead resistance — especially important for precise temperature measurements over longer cable runs.
