MT3608 DC-DC Boost Converter Step-Up Module USB-C 2V–28V 2A
MT3608 DC-DC Boost Converter Step-Up Module USB-C 2V–28V 2A
MT3608 Adjustable Step-Up Voltage Regulator Module with USB-C
Upgrade your electronics projects with the MT3608 DC-DC Boost Converter — a compact, high-efficiency step-up voltage regulator module featuring a convenient Micro USB Type-C plug. Whether you're powering DIY electronics, computer peripherals, or embedded systems, this module delivers stable, adjustable output voltage with up to 93% conversion efficiency.
Made in Mainland China.
Key Features
- Wide Input Range: Accepts input voltages from 2V to 24V and boosts them to a selectable output of 5V–28V — perfect for a broad range of devices and applications.
- Micro USB Type-C Plug: Modern USB-C interface ensures broad device compatibility and reliable power delivery.
- High Efficiency: Achieves up to 93% maximum conversion efficiency, minimizing energy waste and heat generation.
- Adjustable Output: Simply turn the onboard potentiometer to dial in your exact required output voltage — always higher than the input.
- Compact Form Factor: Tiny 36×17×14mm footprint makes it easy to integrate into tight spaces or custom enclosures.
- Up to 2A Output Current: Handles peak current up to 2A, suitable for a wide variety of low-to-medium power loads.
- Integrated Circuit Design: Built around the proven MT3608 IC for dependable, consistent performance.
Specifications
| Input Voltage | 2V – 24V |
| Output Voltage | 5V – 28V (adjustable) |
| Maximum Output Current | 2A (peak) |
| Maximum Efficiency | 93% |
| Product Size | 36 × 17 × 14 mm / 1.42 × 0.67 × 0.55 in (L×W×H) |
| Package Type | SOP |
| Connector | Micro USB Type-C |
| Quantity | 1 piece |
How to Use
Connect your power source (2V–24V) to the input terminals. Use a small screwdriver to turn the onboard potentiometer clockwise or counterclockwise to adjust the output voltage to your desired level. Always ensure your input voltage does not exceed 24V and your load does not draw more than 2A peak current.
Safety Notes
- Do not exceed the maximum input voltage of 24V.
- Peak output current must not exceed 2A.
- Output voltage must always be set higher than the input voltage.
- Ensure proper heat dissipation when running near maximum load.
Package Includes
- 1× MT3608 DC-DC Step-Up Boost Converter Module
Learn more: ENERGY STAR product efficiency guidance
Frequently Asked Questions
Q: What is the input voltage range for the MT3608 boost converter module?
A: The MT3608 step-up module accepts an input voltage between 2V and 24V. Do not exceed 24V input to avoid damaging the module. The output can be adjusted from 5V up to 28V using the onboard potentiometer.
Q: Can I use the MT3608 DC-DC boost converter with a USB-C power source?
A: Yes! This module is equipped with a Micro USB Type-C plug, making it compatible with many modern power adapters and USB-C sources. It's a convenient solution for boosting voltage in a wide variety of electronics and computer applications.
Q: How do I adjust the output voltage on the MT3608 step-up module?
A: Use a small flathead screwdriver to carefully turn the onboard potentiometer. Rotating it clockwise or counterclockwise adjusts the output voltage within the 5V–28V range. Always use a multimeter to verify the output voltage before connecting your load.
